Before installation, be sure to carefully read the instruction manual of the test chamber to understand the performance, characteristics, and installation requirements of the constant temperature and humidity test chamber.
Installation of a constant temperature and humidity test chamber needs to follow the following steps to ensure that the equipment can operate properly and meet the test requirements:
First of all, the installation site is very important. Constant temperature and humidity test chamber requires the storage environment temperature in 5 ~ +30 ℃, if the site because of the season appears too high or too low temperature.
You have to use the cooling or warming equipment to ensure that the temperature is constant, and can not rise and fall. Moreover, it can not be placed in public places or flammable, explosive, easily corrosive chemicals
Nearby, so as not to cause fire or personal injury in the event of failure.
Secondly, the installation location is also delicate. To consider the equipment is easy to check the maintenance and heat dissipation, the body of the machine and the wall and any other machine should be at least 60cm between the above
The distance between the machine body and the wall and any other machine should be at least 60cm, so that the ventilation is smooth. Installed on a flat ground without vibration, adjust the bottom of the body of four flat feet, so that the body balances, in order to drain the inner box and prevent abnormal noise.
Also, constant temperature and humidity test box body should not be subjected to direct sunlight, to be installed in a place where there is no direct sunlight or another heat source of direct radiation. At the same time, to avoid installation
At the same time, to avoid installation in dirty and dusty places, the top of the body shall not be placed in any debris to avoid heavy objects falling down to cause bodily injury and property damage.
In the installation process, the handling should not be sloppy. Don't hold the electric box, electric wire, or motor as the driving force support point to prevent the electric box and electric appliances from being damaged, loosening, or causing unexpected accidents.
Accident. When handling the furnace body tilt should be more than 30 °.
In addition, the constant temperature and humidity test box power supply installation should not be ignored. Power supply using the three-phase five-wire system, the equipment cable for the four-core wire, three-phase line, a zero line, pay attention to the
Zero line distinction. The grounding line of this equipment is equipped with a grounding line column, to ensure that the equipment is well grounded can make the equipment safe and reliable.
